GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477)

OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477)

Stock Number: 3477

GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477), Click to view larger photo...       GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477), Click to view larger photo...       GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477), Click to view larger photo...       GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477), Click to view larger photo...       GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477), Click to view larger photo...       GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477), Click to view larger photo...
Click to view larger photo

Request A Quote On Our Stock Number: 3477 GRINDERS: OVERBECK 400 IR CNC, INSIDE RADIUS/ID/OD, 8 IN. x 10 IN., 30,000 RPM, SWIVEL HEAD, 1992 (3477)Request a quote on stock# 3477
SpecificationDescription
NEW APPROX.1992/1993
MAX. CLAMPING DIAM. OF WORK7.87"
MAX. CLAMPING LENGTH OF WORK9.84"
GRINDABLE BORE LENGTH6.30"
MAX. GRINDABLE BORE DIAMETER5.51"
HEIGHT OF CENTERS5.51"
MAX. WEIGHT OF WORK44 LBS
GRINDING SPINDLE SPEED RANGE6,000 - 30,000 RPM
WORK SPINDLE SPEED RANGE (INF. VARIABLE)28 - 250 RPM
WORKHEAD SWIVELLING RANGE-10� to +90�
WORK SPINDLE FLANGE3.15"
WORK SPINDLE OUTLET1.38"
TABLE MOTION, HYDRAULIC0 - 6 m/min
STEP BY STEP FEED OF SPINDLE0,001 - 0,02 mm
MAIN MOTOR7 HP 460V,3PH,60
DIMENSIONS, APPROX.97"L x 60"W x 70"H

Equipped With:
OVERBECK MICRO CNC CONTROL
6.5" 3-JAW CHUCK
6.5" MAGNETIC CHUCK
COOLANT FILTRATION SYSTEM, PAPER
HYDRAULIC SYSTEM
FULL ENCLOSURE W/WORK LAMP
OIL MIST LUBRICATION UNIT
ALL AVAILABLE ACCESSORIES, SPARE PARTS, AND MANUALS
