MILLTRONICS VM16 CNC MILL, CENTURION 7, 30 x 16 x 20, CAT 40 TAPER, 8000 RPM, NEW 2005

MILLTRONICS VM16 CNC MILL, CENTURION 7, 30 x 16 x 20, CAT 40 TAPER, 8000 RPM, NEW 2005

Stock Number: 4746


Click to view larger photo

Request A Quote On Our Stock Number: 4746 MILLTRONICS VM16 CNC MILL, CENTURION 7, 30 x 16 x 20, CAT 40 TAPER, 8000 RPM, NEW 2005Request a quote on stock# 4746
SpecificationDescription
DATE OF MFG2005
TABLE SIZE45" x 16"
MAXIMUM TABLE LOAD1000 LBS
X AXIS TRAVEL30"
Y AXIS TRAVEL16"
Z AXIS TRAVEL20"
SPINDLE NOSE TO TABLE TOP24"
RAPID TRAVERSE RATE X & Y AXES1000 IPM
CUTTING FEED RATE0.1 - 500 IPM
SPINDLE TAPERCAT 40
SPINDLE SPEEDS50 - 8000 RPM
SPINDLE MOTOR18 HP
TOOL CHANGER CAPACITY16 STATION
WEIGHT, APPROX.9,200 LBS
DIMENSIONS, APPROX.86" x 68" x 102" H

Equipped With:
HIGH SPEED CENTURION 7 CNC PC BASED CONTROL,
USB & RS-232C PORTS INTERFACE FOR DNC OPERATION,
FULL CONVERSATIONAL PROGRAMMING, 3-D GRAPHICS,
4TH AXIS PRE-WIRED WITH DRIVE,
FANUC G-CODE COMPATIBLE,
CHIP REMOVAL AUGER SYSTEM w/CHUTE,
REMOTE JOG HANDLE/WHEEL,
COOLANT SYSTEM W/TANK & PUMP,
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS,
MADE IN THE USA
