CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588)

MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588)

Stock Number: 4588

CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588), Click to view larger photo...
Click to view larger photo

Request A Quote On Our Stock Number: 4588 CNC VERTICAL MACHINING CENTERS: MAZAK V-655 /60 CNC MILL, CAT 50 TAPER, MAZATROL M-PLUS, 60 x 26 x 26 TRAVELS, 6000 RPM, CHIP, BOX WAY, '97 (4588)Request a quote on stock# 4588
SpecificationDescription
DATE OF MANUFACTURE1997
TABLE SIZE68.5" x 25.6"
MAXIMUM PALLET LOAD4,400 LBS
SPINDLE NOSE TO PALLET TOP7.87" - 33.46"
X AXIS TRAVEL59.05"
Y AXIS TRAVEL25.59"
Z AXIS TRAVEL25.59"
RAPID TRAVERSE RATE X & Y AXES1024 IPM
RAPID TRAVERSE RATE Z AXIS787 IPM
CUTTING FEED RATE0.04 - 315 IPM
SPINDLE TAPERCAT 50
SPINDLE SPEEDS (2 SPEED GEARED)25 - 6,000 RPM
SPINDLE MOTOR25 HP
TOOL CHANGER CAPACITY30 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL)2.4 SECONDS
MAXIMUM TOOL WEIGHT44.1 LBS
FLOOR SPACE (APPROX)163" x 174" x 125"
MACHINE WEIGHT (APPROX.)25,240 LBS

Equipped With:
MAZATROL M-PLUS CNC CONTROL WITH 9" CRT SCREEN
RS-232C PORT INTERFACE FOR DNC OPERATION,
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING),
TOOL LIFE MONTIORING, TOOL BREAKAGE DETECTION,
RIGID BOX WAY DESIGN, CHIP CONVEYOR,
STANDARD COOLANT SYSTEM WITH TANK & PUMP,
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
