CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463)

HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463)

Stock Number: 4463

Age: 2008

CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463), Click to view larger photo...       CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463), Click to view larger photo...
Click to view larger photo

Request A Quote On Our Stock Number: 4463 CNC VERTICAL MACHINING CENTERS: HAAS SUPER MINI MILL, HAAS CNC, 16 x 12 x 10, 10000 RPM, ROTARY, '08 (4463)Request a quote on stock# 4463
SpecificationDescription
DATE OF MANUFACTURE2008
TABLE SIZE36" x 12"
MAXIMUM TABLE LOAD500 LBS
SPINDLE NOSE TO TABLE TOP4" - 14"
X-AXIS TRAVEL16"
Y-AXIS TRAVEL12"
Z-AXIS TRAVEL10"
RAPID TRAVERSE RATE X, Y & Z AXES1200 IPM
CUTTING FEED RATE0.1 - 833 IPM
SPINDLE TAPERCAT 40
SPINDLE SPEEDS0 - 10,000 RPM
SPINDLE MOTOR15 HP
TOOL CHANGER CAPACITY10 STATION ATC
TOOL CHANGE TIME (TOOL-TO-TOOL)3 SECONDS
MAXIMUM TOOL WEIGHT12 LBS
MACHINE WEIGHT3,500 LBS
APPROXIMATE DIMENSIONS68" x 68" x 98"

Equipped With:
HAAS TRIPLE HIGH-SPEED 32-BIT CNC CTRL W/15" LCD,
***WIRELESS INTUITIVE PROBING SYSTEM***,
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING),
HIGH FLOW COOLANT PUMP KIT, USB COM. PORT,
CLEAR PLASTIC TOP COVER,
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
