MORI SEIKI SL-25 B/500 CNC LATHE, FANUC 15-T, 21 SW, 24 CENTERS, 20 HP, 3 in. BORE, CHIP CONVEYOR, PARTS CATCHER

MORI SEIKI SL-25 B/500 CNC LATHE, FANUC 15-T, 21 SW, 24 CENTERS, 20 HP, 3 in. BORE, CHIP CONVEYOR, PARTS CATCHER

Stock Number: 4791


Click to view larger photo

Request A Quote On Our Stock Number: 4791 MORI SEIKI SL-25 B/500 CNC LATHE, FANUC 15-T, 21 SW, 24 CENTERS, 20 HP, 3 in. BORE, CHIP CONVEYOR, PARTS CATCHERRequest a quote on stock# 4791
SpecificationDescription
MFG DATE1990
SWING OVER BED20.5"
SWING OVER CROSS SLIDE13.8"
MAXIMUM TURNING DIAMETER10.2"
DISTANCE BETWEEN CENTERS30.6"
MAXIMUM TURNING LENGTH20.9"
X AXIS TRAVEL7.3"
Z AXIS TRAVEL23.2"
SPINDLE NOSEA2-8
SPINDLE BORE3.1"
MAXIMUM BAR CAPACITY2.6"
SPINDLE SPEEDS35 - 3,500 RPM
SPINDLE MOTOR20 HP
TURRET CAPACITY10 STATIONS
RAPID TRAVERSE RATE X AXIS / Z AXIS472 IPM / 590 IPM
TAILSTOCK QUILL TAPERMT #3
TAILSTOCK QUILL DIAMETER/STROKE3.3" / 3.1"
TAILSTOCK BODY TRAVEL19.3"
DIMENSIONS, APPROX.113"L x 68"W x 75"H
MACHINE WEIGHT, APPROX.10,500 LBS w/CHIP CONVEYOR

Equipped With:
FANUC 15-T CNC CONTROL,
RS-232C PORT INTERFACE FOR DNC OPERATION,
AUTOMATIC PARTS CATCHER,
25C COLLET CHUCK, PARTS CATCHER, CHIP CONVEYOR
STANDARD COOLANT SYSTEM WITH TANK & PUMP
ALL AVAILABLE TOOL BLOCK HOLDERS, ALL AVAILABLE MANAULS
