CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506)

AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506)

Stock Number: 4506

CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506), Click to view larger photo...       CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506), Click to view larger photo...       CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506), Click to view larger photo...       CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506), Click to view larger photo...       CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506), Click to view larger photo...       CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506), Click to view larger photo...
Click to view larger photo

Request A Quote On Our Stock Number: 4506 CNC TURNING CENTERS: AMERICAN HUSTLER 2010-78 CNC LATHE, MITSUBISHI M50L, 20 SWING, 78 CENTERS,3.18 BAR, CHIP, RETRO 96, '76(4506)Request a quote on stock# 4506
SpecificationDescription
NEW / RETROFIT1976/1996
DISTANCE BETWEEN CENTERS, MAX.78"
MAX. SWING OVER WAYS20"
MAX. SWING OVER CROSS SLIDE10"
CROSS SLIDE TRAVEL15.5"
SPINDLE THRU HOLE3.18"
SPINDLE NOSEA1-8
SPINDLE SPEEDS (3 RANGES)30 - 3000 RPM
NUMBER OF STATIONS ON TURRET8
TAILSTOCK QUILL DIAMETER4"
MOTOR20 HP
POWER REQUIREMENTS460 / 3 / 60
FULL LOAD50 AMPS

Equipped With:
MITSUBISHI M50L CNC CONTROL,
(1) 10" CHUCK (HYDRAULIC or MANUAL; TAKE PICK)
CHIP CONVEYOR,
HEAVY DUTY TAILSTOCK & QUILL,
EXTRA TURRET FOR CROSS-SLIDE,
***RIGID FLATBED DESIGN
