CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470)

HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470)

Stock Number: 4470

Age: 2007

CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470), Click to view larger photo...       CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470), Click to view larger photo...       CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470), Click to view larger photo...       CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470), Click to view larger photo...       CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470), Click to view larger photo...       CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470), Click to view larger photo...
Click to view larger photo

Request A Quote On Our Stock Number: 4470 CNC TURNING CENTERS: HYUNDAI-KIA SKT250SY, FANUC 18iT, 24.4 SW, 21 CENTERS, LIVE MILLING, SUB, Y-AXIS, CHIP, BAR FEEDER, 2007 (4470)Request a quote on stock# 4470
SpecificationDescription
DATE OF MANUFACTURE2007
SWING OVER BED24.4"
SWING OVER CROSS SLIDE19.3"
MAX. DIST BETWEEN SPINDLES24.8"
X AXIS TRAVEL8.27"
Z AXIS TRAVEL21.7"
Y AXIS CROSS TRAVEL4.33" (+/- 2.17")
B AXIS LINEAR TRAVEL (SUB SPINDLE)27.6"
RAPID TRAVERSE RATE X / Z AXES945 IPM
SPINDLE NOSE (MAIN / SUB)A2-8 / FLAT NOSE
SPINDLE BORE / BAR CAPACITY3.07" / 3"
SPINDLE SPEEDS (MAIN SPINDLE)25 - 3500 RPM
SPINDLE SPEEDS (SUB SPINDLE)30 - 6000 RPM
SPINDLE MOTOR (MAIN / SUB)30 HP / 5 HP
TURRET CAPACITY12 STATION
LIVE TOOLING MOTOR5 HP
LIVE TOOLING SPEEDS1500 - 4000 RPM
MACHINE FLOOR SPACE, APPROX.126" x 78"
MACHINE WEIGHT, APPROX.14,300 LBS

Equipped With:
FANUC 18iT CNC CONTROL,
FULL C-AXIS ON MAIN AND SUB-SPINDLE,
Y-AXIS CROSS TRAVEL (4.33", +/- 2.17")
16C COLLET CHUCKS ON BOTH MAIN AND SUB SPINDLES,
10" 3-JAW FOR MAIN AND 8" 3-JAW FOR SUB,
"Q-SETTER" TOOL PRESTTER ARM, AUTO PARTS CATCHER,
***CNC ENHANCEMENTS MAGAZINE BAR LOADER SYSTEM,
(9) LIVE/REVOLVING TOOL HOLDERS,
RIGHT SIDE LIFT-UP TYPE CHIP CONVEYOR-TURBO,
LARGE ASSORTMENT OF TOOLING, ALL AVAILABLE MANUALS,
STANDARD COOLANT SYSTEM WITH TANK & PUMP
***LESS THAN 300 HOURS***
SEE PHOTOS ATTACHED AND WEBSITE FOR MORE: www.MWMachinery.com
