Request a quote on stock# 4079| Specification | Description |
|---|---|
| APPROXIMATE AGE | 9/1992 |
| MAXIMUM SWING | 17.13" |
| SWING OVER CARRIAGE | 14.56" |
| MAXIMUM TURNING DIAMETER | 9.5" |
| MAXIMUM TURNING LENGTH | 20.87" |
| X AXIS TRAVEL | 7.09" |
| Z AXIS TRAVEL | 22.08" |
| RAPID TRAVERSE RATE X & Z AXES | 1181 IPM |
| SPINDLE BORE | 2.4" |
| SPINDLE SPEEDS | 50 - 5,000 RPM |
| SPINDLE MOTOR | 20 HP |
| TURRET CAPACITY | 12 STATION TURRET |
| LIVE TOOLING MOTOR | 5 HP |
| LIVE TOOLING SPEEDS | 100 - 3,000 RPM |
| SUB SPINDLE MOTOR | 10 HP |
| TAILSTOCK STROKE | 15.75" |
| TAILSTOCK QUILL DIAMETER / TAPER | 3.14" / MT #4 |
