HAAS HS-2RP, HAAS CNC, 24 x 20 x 20, 0.001 DEG, 10000 RPM, 30HP, LOADED, '00 (4202)
Stock Number: 4202
Age: 2000
Click to view larger photo
Request a quote on stock# 4202
| Specification | Description |
|---|
| DATE OF MANUFACTURE | 5/2000 |
| PALLET SIZE | 20" x 20" |
| MAXIMUM PALLET LOAD | 1200 LBS |
| NUMBER OF PALLETS | 2 |
| SPINDLE CENTER TO PALLET TOP | 3.88" - 38.88" |
| SPINDLE NOSE TO PALLET CENTER | 5.125" - 36.125" |
| X AXIS TRAVEL | 38" |
| Y AXIS TRAVEL | 35" |
| Z AXIS TRAVEL | 31" |
| B AXIS INDEXING | 0.001 DEG. |
| RAPID TRAVERSE RATE X, Y & Z AXIS | 710 IPM |
| CUTTING FEED RATE | 0.1 - 500 IPM |
| SPINDLE TAPER | CAT 40 |
| SPINDLE SPEEDS (2 SPEED GEARED) | 0 - 10,000 RPM |
| SPINDLE MOTOR | 40/30 HP |
| TOOL CHANGER CAPACITY | 40 STATION ATC |
| MAXIMUM TOOL WEIGHT | 12 LBS |
| DIMENSIONS (APPROXIMATE) | 193" x 173" x 121" |
| MACHINE WEIGHT (APPROXIMATE) | 25,000 LBS |
Equipped With:
HAAS CNC CONTROL WITH 12" COLOR CRT SCREEN
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
COOLANT THROUGH THE SPINDLE (140 PSI RATING)
AUXILLIARY COOLANT FILTER, 8 MB EXTENDED MEMORY
OPTIONAL 10000 RPM SPINDLE WITH 30HP MOTOR
1000 BLOCK PER SECOND LOOK AHEAD FUNCTION
HELICAL INTERPOLATION, INCH/METRIC CONVERSION
FLOOD COOLANT SYSTEM, REMOTE PULSE GENERATOR
1.44MB FLOPPY DISK DRIVE, QUIKCODE PROGRAMMING
COORDINATE ROTATION & SCALING, CUSTOM MACROS
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
***FORMER WESTEC DEMO - INSTALLED LATE 2002***
SEE PHOTOS ATTACHED AND WEBSITE FOR MORE: www.MWMachinery.com
